Multiformat support to decode any stream
Input and output options include ASI, MPEG/IP, DVB/S/S2/S2X, QAM/VSB, DVB-T/T2, C/C2 and ISDB-T
ST 2110, SDI and HDMI output options
Dense any‑codec ASIC based decoder for distribution decode
Monitor UHD and 1080p60 signals via SDI or HDMI
Decode UHD streams for re‑encode and monitoring
The AG 6000 is a new UHD receiver decoder card for the openGear® form factor. Built with the latest generation ASIC to deliver a dense, cost-effective multiformat decoding solution. Perfect for applications such as monitoring, digital-turnaround, digital signage, hospitality and enterprise video delivery.
The AG 6000 will decode HEVC/H.264/MPEG2 and output UHD/HD/SD video with 4 audio services (8 audio channels) with all ancillary data required for professional video delivery networks. Input and output options include ASI, MPEG/IP, DVB/S/ S2/S2X, QAM/VSB, DVB-T/T2, C/C2 and ISDB-T. Licenses and hardware options for descrambling include with BISS and dual DVB-CI CAM slots.
The AG 6000 maintains our long tradition of ease of use, with a straight-forward user interface and web APIs and backed by Sencore’s best-in-class staff of ProCare support engineers.
openGear® is a registered trademark of Ross Video
Download the latest version of openGear Dashboard control software here.
